    OEM 8W / 10W IP54 / II Industrial Electric Unit Heaters Screw Fixing Mounting Screw Fixing

    8W / 10W IP54 / II Industrial Electric Unit Heaters Screw Fixing Mounting Screw Fixing


    ● Temperature limiting

    ● Wide voltage range

    ● Dynamic heating up

    ● saving

    ● Compact


    These small heaters are designed to prevent condensation and to ensure a minimum operating temperature in small enclosures.

    TECHNICAL PARAMETER

    Operating voltage

    120-240V AC/DC* (min. 110V, max. 265V)

    Heating element

    PTC resistor, temperature limiting

    Heater body

    aluminium, anodised

    Mounting

    screw fixing

    Fitting position

    variable

    Operating/Storage temperature

    -45 to +70 °C (-49 to +158 °F)

    Operating/Storage humidity

    max. 90 % RH (non-condensing)

    Protection type/Protection class

    IP54 / II (double insulated)

    Approvals

    VDE + UL File No. E150057

    Note

    other voltages on request

    * Operating with voltages below 140V AC/DC reduces heating performance by approx. 10%.


    Art. No.Heating capacity*Inrush current max.Pre-fuse T (time-delay)Surface temperature (apprpx.)ConnectionWeight (approx.)
    01602.0-008W2.0A1A150°C2 x AWG 18 stranded wire20g
    01609.0-0010W2.5A2A155°C2 x AWG 24 sheathed cable (silicone)30g
    01610.0-0013W3.0A2A170°C2 x AWG 24 sheathed cable (silicone)40g
    *at 20°C (68°F) ambient temperature

    WIRING DIAGRAM

    Product picture
