    CJX2 LC1 50HZ AC Circuit Contactor Combined Into Electromagnetic Starter

    Ask Lasest Price
    Brand Name : Winston/OEM
    Model Number : CJX2(LC1)
    Certification : CE,ROSH
    Payment Terms : T/T,L/C,Paypal,Online Payment,RMB/USD
    Supply Ability : 10000PCS/Month
    Delivery Time : 3-15days after get payment.
    • Product Details
    • Company Profile

    CJX2 LC1 50HZ AC Circuit Contactor Combined Into Electromagnetic Starter

    CJX2 LC1 50HZ AC Circuit Contactor Combined Into Electromagnetic Starter


    CJX2 series AC Contactor is suitable for using in the circuits up to the rated voltage 660V AC50Hz or 60Hz, rated current up to 620A, for making, breaking, frequently starting & controllingthe AC motor. Combined with the auxiliary contact block, timer delay & machine-interlockingdevice etc, it becomes the delay contactor, mechanical interlocking contactor, star-delta starter.With the thermal relay, it is combined into the electromagnetic starter. The product conforms toIEC60947-4-1 stardand.

    TECHNICAL PARAMETER

    TypeCJX2-D09CJX2-D12CJX2-D18CJX2-D25CJX2-D32CJX2-D40CJX2-D50CJX2-D65CJX2-D80CJX2-D95
    Rated workingcurrent (A)AC39121825324050658095
    AC43.557.78.51218.524283744

    Standardpower ratingsof 3-phasemotors

    50/60Hz incategory AC-3

    220/230V2.2345.57.5111518.52225
    380/400V45.57.5111518.522303745
    415V45.5911152225374545
    500V5.57.5101518.52230375555
    660/690V5.57.5101518.53033374555
    Rated heat current (A)2020324050608080125125
    Electrical lifeAC3 (x104)100100100100808060606060
    AC4 (x104)20202020201515151010
    Mechanical life (x104)1000100010001000800800800800600600
    Number of the contacts3P+NO3P+NC+NO
    3P+NC

    Standard Control Circuit Voltage

    Volts244248110220230240380400415440500600
    50HzB5D5E5F5M5P5U5Q5V5N5R5S5Y5
    60HzB6D6E6F6M6-U6Q6--R6--
    50/60HzB7D7E7F7M7P7U7Q7V7N7R7--
