LM12 Non Flush Inductive Proximity Sensor DC 10V 3 / 2 Wire Proximity Switch

Ask Lasest Price
Brand Name :	Winston/OEM
Model Number :	LM12
Certification :	CE,ROSH
Price :	Negotiable
Payment Terms :	T/T,L/C,Paypal,Online Payment,RMB/USD
Supply Ability :	10000PCS/Month
Delivery Time :	3-15days after get payment.

Add to Cart

Product Details
Company Profile

LM12 Non Flush Inductive Proximity Sensor DC 10V 3 / 2 Wire Proximity Switch

LM12 Non Flush Inductance Sensor DC 10V 3 Or 2 Wire Proximity Switch

Features:

Compact volume, High on-off frequency
High precision of repeated location
Good performance of anti-interference
Many output forms, Wide voltage range
Dust proof, vibration proof, water proof and oil proof
With short-circuit protection and inverted
connecting protection
Long service life

Technique parameter

	DETECTION DISTANCE 2mm
Flush	DC 10-30V	NPN	NO	LM12-3002NA
			NC	LM12-3002NB
			NO+NC	LM12-3002NC
		PNP	NO	LM12-3002PA
			NC	LM12-3002PB
			NO+NC	LM12-3002PC
		two wire system	NO	LM12-3002LA
			NC	LM12-3002LB
	AC 90-250V	SCR Control-lable silicon	NO	LM12-2002A
			NC	LM12-2002B
			NO+NC
		Relay output
	DETECTION DISTANCE 4mm
Non-Flush	DC 10-30V	NPN	NO	LM12-3004NA
			NC	LM12-3004NB
			NO+NC	LM12-3004NC
		PNP	NO	LM12-3004PA
			NC	LM12-3004PB
			NO+NC	LM12-3004PC
		two wire system	NO	LM12-3004LA
			NC	LM12-3004LB
	AC 90-250V	SCR Control-lable silicon	NO	LM12-2004A
			NC	LM12-2004B
			NO+NC
		Relay output
Controloutput		DC		200mA
		SCR/ Relay
Output voltagc dropDC/AC				NPN/PNP< 3V, Two wire< 3.9V, AC< 10V
Consumption current				DC< 15mA, AC< 10mA
Standard detected object				15151(A3 iron)
Repeated precision				0.01
DC/AC				400Hz/25Hz
Working environment temperature				-25º C~+70º C
Insulation resistance				50MΩ
Shell material				Metal
Protection grade				IP67
Altemative model at home and abroad				E2E-X5

Model explanation of proximity switch

LM 18 30 05 N A □ / L

—— —— - —— —— —— —— —— ——

1 2 3 4 5 6 7 8

Switch category	Output form
Lm: Inductance type Cm: Capacitance type Sm: Hall type Am: Safety Explosion-proof type Xm: Mimic Linear type Hm: Reed type Ru: Ultrasonic type	N: Three-wire Dc NpN Output P: Three-wire Dc PnP Output L: Two-wire Dc Output : Ac Two-wire Output J: Relay Contact Output Np: NpN+PnP Double Output
Outward appearance code	Output state
□: Cylinder type F□: Angular Colum Type And Plane Installation Type	A: (no) normally Open (no) B: (nc) Normally Close (nc) C: (no-nc) normally Open-Normally Close (no+nc) Mu: Mimic Voltage Mi: Mimic Current Mui: Voltage+Current
Working voltage	Subsidiart functions
30: 6-36VDC 310:5-24VDC 320:12-60VDC 330: 10-30VDC 340:10-55VDC 350:10-60VDC 360: 5-36VDC 20:90-250VAC 210:24-250VAC 220: 380VAC40:12-240VDC/24-240AC 50: Special voltage	T: with aviation connector Y: water proof,oil proof I: special requirement H: high temp resistance R: ring type
Detection distance	Long-distance
01:1mm 05:5mm 10:10mm ......	L: Long-distance

Working priciple inductive proximity switch

Inductive proximity switch is composed of three parts:oscillator,switch circuit and magnified output circuit.The oscillator will generate an alternating electric field.When hemetal object approaches this electric field and reaches the induction distance, whirlpool will generate in metal object, resulting in attenuation of vibrati on and then stop.The changeof vibration and stop of oscillator is treated by begid stage magnified circuit and convertedto switching sign,triggering driving con-contact detection.

Current consumption of inductive proximity switch decreases proportional to the metal object distance.

Application illustration of proximity switch

1. Various location detection of machinery process center

2. Bottle lid detection

3. Detecting whether there is the milk in the package

4. Inspection of the exiating of milk inside the paper package

Dimension
