Classic Normal 12V 350W Single Output Switch Mode Power Supply S - 350 Series

    Buy cheap Classic Normal 12V 350W Single Output Switch Mode Power Supply S - 350 Series from wholesalers

    Buy cheap Classic Normal 12V 350W Single Output Switch Mode Power Supply S - 350 Series from wholesalers
    • Buy cheap Classic Normal 12V 350W Single Output Switch Mode Power Supply S - 350 Series from wholesalers
    • Buy cheap Classic Normal 12V 350W Single Output Switch Mode Power Supply S - 350 Series from wholesalers
    • Buy cheap Classic Normal 12V 350W Single Output Switch Mode Power Supply S - 350 Series from wholesalers

    Classic Normal 12V 350W Single Output Switch Mode Power Supply S - 350 Series

    Ask Lasest Price
    Brand Name : Winston/OEM
    Model Number : S-350W 12V 15V 24V 48V
    Certification : CE,ROSH
    Price : USD18.26 to USD20.9
    Payment Terms : T/T,L/C,Paypal,Online Payment,RMB/USD
    Supply Ability : 10000PCS/Month
    Delivery Time : 3-15days after get payment.
    • Product Details
    • Company Profile

    Classic Normal 12V 350W Single Output Switch Mode Power Supply S - 350 Series

    Classic Normal S-350 Seires 12V 350W Single Output Switch Mode Power Supply

    Feature

    Built-in active power factor correction(PFC) function for SP models

    Built-in EMI filter, extreme low ripple

    100% full load burn-in test


    Application : Industrial control, security, intelligent building, LED lighting etc.fields


    Summary

    • Single output: power 350w
    • Input voltage: 90-132VAC/180-264VAC

    Technique parameter:

    Model

    S-350

    -5

    S-350

    -9

    S-350

    -12

    S-350

    -15

    S-350

    -18

    S-350

    -24

    S-350

    -27

    S-350

    -36

    S-350

    -48

    S-350

    -60

    S-350

    -70

    S-350

    -110

    DC output voltage current5V 0-50A9V 0-38A12V 0-29A15V 0-23.3A18V 0-19.4A24V 0-14.6A27V 0-13A36V 0-9.7A48V 0-7.3A60V 0-6A70V 0-5A110V 0-3.2A
    Wave and noise

    150

    mVp-p

    150

    mVp-p

    150

    mVp-p

    150

    mVp-p

    150

    mVp-p

    150

    mVp-p

    150

    mVp-p

    150

    mVp-p

    150

    mVp-p

    200

    mVp-p

    200

    mVp-p

    240

    mVp-p

    Inlet stability±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%
    Load stablity±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%±0.5%
    Efficiency73%78%83%83%84%85%85%85%86%86%86%86%
    Adjustable range for DC voltage±10%±10%±10%±10%±10%±10%±10%±10%±10%±10%±10%±10%
    input voltage range90-132VAC/180-264VAC by switch 254-370VDC 47-63Hz
    Inpact currentCold start current 50A/230VAC 25A/115VAC
    Overload proctection105%-135% cut off the output, automatic recovery
    Over-voltage protection115%-150% shut down O/P voltage, re-power on to recover
    Setup rise hold up time200ms, 50ms, 20ms/230vac at full load
    Withstand voltage

    I/P-O/P: 1.5KV I/P-FG:1.5KV O/P-FG:0.5KV 1minute

    Isolation resistanceI/P-O/P I/P-FG O/P-FG: 500VDC/100MΩ
    Working temperature-10℃~+50℃
    Overall dimension215*115*50mm
    Weight1kg
    Packing45.5*31.5*26cm/20PCS/20kg

    PS: If you can't find the exact type of your product.Please don't rush to go away.Contact me and your questions will be replied ASAP.Thank you for your time.


    Our Services


    1. Prompt reply: Any inquiry or questions would be replied within 24 hours.

    2. Quality Product: Manufacture company, each of the products is tested and calibrated.

    3. Hospitality: Offer smiling service and your visiting is highly welcomed

    4. Fast delivery: delivery time is within 3-7 days usually, other occasion depends on the order qty.


    Dimensions
