    3NO Air Conditioning Parts 220 Volt 3 Pole Small AC Contactor Electrical

    Ask Lasest Price
    Brand Name : Winston/OEM
    Model Number : WCT 63A 3P 3NO
    Certification : CE,ROSH
    Price : USD7.33 to USD10.33
    Payment Terms : T/T,L/C,Paypal,Online Payment,RMB/USD
    Supply Ability : 10000PCS/Month
    Delivery Time : 3-15days after get payment.
    • Product Details
    • Company Profile

    3NO Air Conditioning Parts 220 Volt 3 Pole Small AC Contactor Electrical

    Manufacturer 3NO Air Conditioning Parts 220 Volt 3 Pole Small AC Contactor


    Features

    WCT series household AC contactors are suitable for controlling household appliances & similar usages low micro-load, also controlling household motors loading, whose controlling power shall be reduced, The products are used for family , hotel , apartment etc. places, And, it can be realized automatic function.


    Advantage

    * Convenient installation, volume reduction 70%.
    * Energy consumption decreased by 75%.
    * Compared with the traditional contactor, ultra quiet, less than 15dB, no worries.

    Technical data

    WCT contactors-50Hz
    Raring(In)Control voltage(V AC)(50Hz)ConsumptionMax.

    power
    AC7aHoldingInrush
    3P63 A220…2406.5 VA53 VA2.1 W

    Power circuit
    Voltage Rating(Ue) 1P, 2P
    250VAC
    3P, 4P
    400VAC
    Endurance(O-C)
    Electrical
    100000 cycles
    Maximum number of switching operation a day
    100
    Additional characteristics
    Insulation voltage(Ui)
    500VAC
    Pollution degree
    2
    Rated impulse withstand voltage(Uimp)
    2.5kV(4 kV for 12/24/48V AC)
    Degree of protection

    (IEC 60529)
    Device in modular enclosure
    IP40
    Tropicalization (IEC 60068-1)
    Treatment 2(relative humidity 95% at 55℃)

    Working principle

    The working principle of the contactor: Upon energization, the circuit with current will create a magnetic field and generate sufficient magnetic adhesion to overcome counterforce, close armature and connect the contacts.


    When the coil voltage dies out or reduces to a certain value(i.e. at the state of voltage release), for the flux generated at the end face of the armature decreases, the magnetic adhesion becomes weaker than the counterforce generated by the reaction spring, contact spring, etc.


    Attention

    First confirm whether the product voltage, current, frequency and use category meet the requirements before use;


    Second connect the control circuit first for no-load operation test and then connect the load in case of no abnormality;


    Third regularly tighten the terminals and remove the deposited dust;


    Dimension
